Fire Extinguisher

ABC or Multi-Purpose Fire extinguishers comprise of a special fluidized and siliconized mono ammonium phosphate dry chemical powder. It chemically insulates Class A fires by melting at approximately 350°F and coats surface to which it is applied. It smothers and breaks the chain reaction of Class B fires and will not conduct electricity back to the operator. FEATURES : Stored Pressure Design Drawn Steel Cylinders Durable High Glossy Powder coating Squeeze Grip type discharge Valve and cap made out of Brass with Chrome Plated BIS approved MAP based multi-purpose powder BIS 15683 Approved Maintenance should be done as per IS 2190 ::2010 User Friendly : Easy and More Economical to Maintain and Service

Arihant Fire offer the superior performance and reliability you expect from quality products. CLEAN AGENT applications where the agent must be clean, electrically nonconductive, environment-friendly, extremely low in toxicity and exceptionally effective. FEATURES Stored Pressure Design Deep Drawn Steel Cylinders Squeeze Grip type discharge Valve made out of Brass with Chrome Plated Residue-free Hydro Fluorocarbon Gas Agent Pressurized with dry Nitrogen. Excellent Replacement For Halon 1211 Extinguishers. High Performance Extinguishing Agent. BIS 15683 Approved Maintenance should be done as per IS 2190: 2010 USEFUL FOR : Computer Rooms / Laboratories Server-data Room / Tele-communications Aerospace- Warehouse Hospitals - Medical Equipments Sensitive Expensive Equipment USER FRIENDLY : No Electrical Conductivity Back To The Operator No Thermal Or Static Shock ENVIRONMENTALLY ACCEPTABLE : EPA approved "Clean Agent" for Class A, B and C class hazards Low GWP (Global Warming Potential) Low ODP (Ozone Depletion Potential) Short Atmospheric Lifetime TECHENICAL SPECIFICATIONS :

Foam has the ability to form an aqueous film which quickly over water-insoluble hydrocarbon fuel surfaces causing rapid fire extinguishment and vapor suppression for class B fires. Also it provides excellent penetrating and wetting qualities when used on class A fires. Hence, foam extinguishers are ideal for fires involving volatile liquids and freely burning materials such as lubricant, oil fires, paper, cloth, wood, etc. FEATURES : Only for fighting class A and B fire Drawn Steel Cylinders Squeeze Grip type discharge Valve and cap made out of Brass with Chrome Plated High quality epoxy polyester powder coated BIS 15683 Approved Maintenance should be done as per IS 2190:2010 User Friendly : Easy and More Economical to Maintain and Service Warning : Do not use on electrical fires.

Fire is a calamity that strikes without any warning and causes an unimaginable havoc. According to a survey conducted, 80% of the most damaging fires occur during night times, weekends or holidays when no one is around. Hence an automatic operation is the only solution for round-the-clock protection against any kind of fire. Fire Stone fire extinguishers are simple and economical solution for buildings or structures where detection and suppression piped systems prove cumbersome and very expensive. How Do They Work? When heat from an uncontrolled fire increases to a pre-set temperature of the unit, the fusible link releases, discharging the extinguishing agent. The release temperature of the extinguisher (fusible link) can be pre-set at works ranging from 57 deg C/68 deg C/79 deg C/93 deg C/140 deg C and so on. They require no external source of energy and it can be operated electrically manually or mechanically for their operation. Salient Features An Automatic Detection and Suppression System together in a single unit quite unlike any other system available in the market Automatic round-the-clock protection Available in individual units or as a Complete system Automatic, hence no human involvement, reducing the chances of injury and accidents to virtually zero. Proves to be the most economical w hen compared and no surface re-laying Reusable cylinder as it is not based on aerosol technology. Hence, most economical Non-Freezing & long lasting. Contents Available with either ABC all purpose Dry chemical powder, Purple k , UL listed ABC powder , or HFC-227ea and HFC-36 (also known as FM-200TM, a registered trademark of Great Lakes Chemical Corporation or as Dupont's FE-227TM, range of extinguishing agents. As HFC-123 more commonly known as HALOTRON is slated to be phased out after 2013, Fire Stone does NOT recommend it to its clients. Electro Piston Actuator (Optional Feature) Switch can be linked into the wiring circuit for electric operation with solenoid actuator. This additional special facility can be attached at minimum extra cost. Mounting Arrangement (Optional Feature) Mounting Arrangement can be designed for special application request. Applications In Industries of following Types : Powder, Textile,Chemicals, Fertilizers, Petrochemicals, Refineries, Ceramics, Metal Processing, Vegetable Oil, Rubber, Wood, Paper and Pulp, Printing, Plastic, Paint, Computer etc. having special process hazards like Boiler & Furnaces, Fluid Power Systems, Oil quenching, Spray Finishing, Powder Coating, Dipping and Coating, Welding & Cutting, Grinding, Solvent Extraction, Conveyor Systems, Aerosol Charging, Transformers & Electrical Junction Boxes, Control Panels etc. Applicability for General Occupancies & Storage Areas Like Storage of Flammable & Combustible Liquids and Gases, Grain Mill Products Solid Fuels, Records, Libraries, Museums, Showrooms, Shops, Offices, Residential premises, Workshop, Garages, Paint Booths, Theaters, Radio Rooms, TV Stations etc. The Common Features For All Models Expellant : Nitrogen Cylinder Test Pressure : 30 kgf /cm2 Cylinder : Stainless Steel / M. S. Plate Powder coated
